Minute Man Electronics

Unique Products and Components


$20.00 Minimum Merchandise Order
Mini-LAN TesterMini-LAN Tester
Eclipse Model 400-018

Used for verifying and troubleshooting live networks. Displays link status, link speed of 10Mbs or 100Mbs, PC vs. Hub.
Click Here For Larger Image

Price:  $78.46


Test, Verify and Repair Lan Tester
Model TVR10/100K

The TVR10/100 plugs into active hubs and/or PCs to verify 10Base-T or 100Base-T operation. Only the Main Unit is required for these tests.
  • Verifies if PC is ON, if it appears as a PC and maximum speed.
  • Verifies if hub is ON, if it appears as a hub and maximum speed.
  • Verifies PC to hub speed and data transmission.
  • Verifies hub to hub data transmission.
  • Checks if straight thru or crossover patch cable is required.
  • Finds speed bottlenecks on 10 and 100 Base-T LANs.
  • On-line monitors LAN link (between two devices).

Cable Testing. The following tests are performed by the TVR10/100 Main Unit and Remote Unit (except where indicated).

  • Locates miswired cables.
  • Locates missing cables.
  • Locates cables that can not support 100Base-T operation (for LANs that require 4 pair wiring).*
  • Tests connection to hub (pairs connected to hub).*
  • Tests connection to PC (pairs connected to hub).*
  • Tests installed cables (pairs wired and type).
  • Tests patch cables (pairs wired and type).
  • Remote Probe helps locate and trace inactive cables.
  • Remote Probe traces active cables connected to hubs and PC without interfering with LAN performance.

*Test performed by the Main Unit only (does not require the use of the Remote Probe).


Additional Information

Price:  $179.95

Test, Verify and Repair Lan Tester


Cable Sniffer with RemoteCable Sniffer with Remote
Eclipse Model 400-019

This remote cable teser is a palm-sized unit for testing today's most popular cabling systems:

  • RJ-45 for testing USOC 4/6/8, Ethernet 10Base-T, EIA/TIA-568B, ATT 258A, Token Ring and any other cabling systems with RJ-45 connectors.
  • RJ-11 for testing Telephone, PhoneNet and any other cabling systems with RJ-11 connectors.
  • USB for testing USB, and any other cabling systems with USB connectors.
  • BNC for testing Ethernet 10Base-2/10-Base-5 terminator value.

General Features with 5 LED's (Plus 9 LED pin display) to indicate:

  • Open/Short Wiring
  • Connected wires displayed
  • No wire or termination indication
  • Wrong connection / No-parallel connection
  • Ethernet 10Base-2/10 Base-5 termination value detection
  • 9V Battery Power (Battery not included)

Click Here For Larger Picture

Price:  $76.95
